Silky999

+1 to not over-tighten the locking screws(A). I did that on one of mine on my 1989 Ibanez SR800LE and it fractured the saddle. Trying to find another new or used 206/omni-adjust bridge is near impossible so I had to repair using JB Weld. The only other viable option would be a bridge replacement for something more modern. Luckily the repair has held so far and I just leave well alone now.

I have spent the weekend building a larger waist height spray booth from my version 1 as it was a little too small to be comfortable. The dimensions now are 150cm wide x 100cm high x 80cm deep with a 6” extraction fan. Made from 18mm MDF. The front bottom panel is on hinges so I can open it up to be horizontal when spraying to aid airflow and a barrier for floor dust. It is also a handy place to mix paint and thinners. There is also a front top panel so that the front opening is restricted slightly. Extraction is on the bottom left of the back panel with a baffle to hopefully encourage downwards cross flow across pieces. The jig is a Billy Boy. i also upgraded to a used Devilbiss GTI PRO LITE 1.4 CLEAR with T110 air cap which is my dedicated clear coat gun now. It is a massive improvement over my budget guns and the finish results are so much smoother. One of the old guns will be my base coat and the other set up for primer. Air is from a SIP QT 100 litre compressor with 16 CFM displacement and 13 CFM FAD. The compressor is only about 63dB so much quieter and more efficient than my previous one. Finish-wise, I am using nitro paint and clear, 1k polyurethane clear and am going to try some 1k acrylic clear on a future build. It’s too dangerous to use the 2k stuff without a proper air fed respirator and certainly not in a garage attached to the house!

For the Jack, I would rewire to the old Jack if possible

First coats of poly on the Wenge and Elm J bass Paulownia Musicman and Walnut shortscale P bass finished with their satin nitro alongside @HeadlessBassist Walnut J bass that’s is all polished waiting for its graphite neck to arrive.

If @HeadlessBassist decides that it doesn’t work with his pickguard, I will put it up for sale on BC once I’ve cleaned the polish out of the holes lol

As promised…..It really is very glossy lol

I will take some photos….

Potential Walnut control plate finished for @HeadlessBassist walnut jazz bass build. Just waiting for his graphite neck to land and the assembly will begin!!

+1 for Earl Pilanz……got one for my G & L L2000 from him.

I use Liberon Finishing Oil which dries to a hard finish and hand sand it in. Depending how many coats you apply dictates the level of sheen from satin to a good gloss. I then wax, nitro or poly. This wenge and elm is just Liberon and nothing else and was only a couple of coats in at this point.

A day using the spray booth and I think I’m getting better lol. Walnut, Paulownia and Sapele.

Testing out the new branding iron on the walnut short scale with nitro clearcoat.

First coats of satin nitro…..
